| General Parameter |
| CPU |
4 core 64 bit Coretex-A53,1.3GHz |
| Operation system |
Android 7.0 |
| Memory |
RAM:2GB ROM:16G; support 128GB Micro SD card |
| Screen |
5 inch IPS screen, resolution 720*1280 |
| Touchscreen |
Corning Gorilla 3rd generation industrial multi-touch capacitive Screen |
| Expansive |
1 sim card slot,2 PSAM card slot |
| Communication port |
USB 2.0; 3.5 plug charging port |
| Audio |
Support voice broadcast |
| Keyboard |
Scan key, function key |
| GPS |
Build-in GPS, accuracy±5m |
| Camera |
Rear 8 million pixel camera with flash, auto focus function |
| Communication Parameter |
| 4G |
TD-LTE Band38/39/40/41
FDD-LTE Band 1,2,3,4,7,17,20 |
| WIFI |
2.4G/5G dual frequency, support IEEE802.11a/b/g/n |
| Bluetooth |
Bluetooth 4.0 |
| Barcode Parameter (Optional) |
| 1D barcode module |
Honeywell N431X |
| Support 1D type |
Code 39, Code 93, Code128, Codebar, EAN- 13, EAN- 8, UPC-A, UPC- E, ITF 14, UCC/EAN- 128, ITF25, Matrix 25, EAN-128, ISBN etc |
| 2D barcode module |
Honeywell-6603 |
| Support 2D type |
PDF417, MicroPDF417, Composite, RSS, TLC-39,Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes,US PostNet,US
Planet, UK Postal, Australian Postal,Japan Postal, Dutch Postal etc |
| Fingerprint Parameter (Optional) |
| Module function |
Fingerprint capture/contrast/deletion, image processing, etc |
| Sensor |
TCSI biometric fingerprint/FBI fingerprint authentication |
| Sensor type |
Capacitive inductance: 256*360pixel,500 DPI |
| Storage capacity |
1000pcs |
| RFID Parameter |
| 2.4Ghz RFID |
| Working frequency |
ISM 2.4-2.48GHz |
| Receive sensitivity |
-90dBm |
| Reading distance |
0-50m (open area, tag type matters) |
| Reading speed |
200pcs/s |
| Developing kit |
APK and source code |
| UHF RFID(Optional) |
| Working frequency |
865-868MHz or 902-928MHz |
| Protocol |
EPC C1 GEN2 /ISO18000-6C |
| Reading distance |
4-7m(tag type matters) |
| HF RFID(Optional) |
| Working frequency |
13.56Mhz |
| Protocol |
ISO15693/ISO1443A |
| Mechanical&Electrical Parameter |
| Weight |
400g default active |
| Dimension |
170*85*23±2mm (Cradle excluded) |
| Battery |
4500mAh Lithium polymer battery ( more than 12 hours working time) |
| IP rating |
IP66, withstand 1.5m drop |
| Temperature |
Working :-20°C ~ 50°C; Storage: -40°C ~ 70°C |
| Accessary |
| Standard Accessary |
Lithium battery, power adaptor, DC charging cable, USB cable |
| Optional |
Bag, cradle |
