Mid Range HF Desktop RFID Card Reader USB RFID Scanner Support Host And Scan Work

₹ On Request

This is an integrated desktop RFID card reader that integrates a reader/writer module and antenna into one unit. This advand reader reads tags compliant to ISO15693 and ISO14443A/B standards. It provides high-sensitivity read and write capability and an efficient anti-collision algorithm.

Specification

Product Name Mid Range HF Desktop RFID Card Reader USB RFID Scanner Supporting Host and Scan Work
Operating Frequency 13.56 MHz (HF RFID)
RF Power Output 0.5W - 1W (Typically)
Voltage 5V DC via USB
Communication Interface USB 2.0 (for easy integration with computers or host systems)
Tag Types Supported ISO 14443A/B, ISO 15693, Mifare Classic, Mifare DesFire, NTAG
Detection Range Up to 10 cm (close range, depends on tag and environment)
Card Reading/Scanning Capability Supports reading of RFID tags and cards with host and scan functionality
Operating Temperature -10°C to +50°C

  • Additional Information:

    • Relative Humidity 10% - 90% (non-condensing)
    Power Consumption Typically 0.5W - 1W
    Mounting Type Desktop Mount (Stand-alone unit)
    LED Indicators Yes (Green/Red LED for status indication, read/write operations)
    Buzzer Yes (For successful/failed read or scan operation)
    Dimension Typically 120mm x 100mm x 30mm (varies by model)
    Weight Typically 0.2 - 0.5 kg
    IP Rating IP42 or IP54 (depends on model)
    Software Compatibility Integration with card management software, SDK/API
    Security Features Secure data reading, optional encryption for data security
